GENERAL FEATURES
External panels, back panel, doors and worktop in AISI 304
18/10 stainless steel (with Scotch-Brite satin finish) External base in AISI 304 18/10 stainless steel Inner lining with rounded corners in AISI 304 18/10 stainless steel Worktop with chilled compartment for insertion of container made GN1/3, GN 1/2 and submultiples
Die-formed leakproof floor ledge Insulation in high density (42 kg/m³ approx.) expanded polyurethane,
50mm thick, HCFC-free Copper evaporator coil with aluminium fins protected against corrosion with non-toxic paint finish,using electrolytichal process Paint-finished steel condenser coil, with high thermal efficiency Anti-condensation heating elementon the body below the magnetic seal stop ergonomic
handle throughout full width of door/drawer and magnetic seals on all four sides
Stainless steel feet Ø 2” with adjustable H 150÷200 mm Self-closing doors locking in open position at 100°
INTERNAL SET-UP
Snap-in type AISI 304 18/10 stainless steel slides and uprights,
completely removable without the need of tools to facilitate cleaning
one shelve 600x400mm for each full door module
COOLING UNIT
Evaporator with high-power fan to ensure maximum cooling system efficiency
