Friulinox

GENERAL CHARACTERISTICS Monoblock construction with internal and external finish in AISI 304 18/10 stainless steel (Scotch-Brite satin finish) External back panel in prepainted steel External base panel in AISI 304 steel Internal die-formed leakproof floor 75 mm thick insulation in water-based polyurethane foam with density approx. 42 kg/m³ Copper evaporator coil with aluminium fins protected against corrosion with non-toxic paint finish Painted steel condenser coil with high thermal efficiency Relative humidity adjustment (min/max - RH%) Magnetic gasket on the four sides and counter-magnet on the gasket ledges Door in AISI 304 18/10 stainless steel (Scotch-Brite satin finish) Self-closing door with block in open position at 100° Ergonomic full-height door handle Stainless steel feet Ø 2’’ adjustable H 150-180 mm INTERNAL SET-UP Uprights and ‘C’ guides in AISI 304 18/10 stainless steel, removable without the use of tools for easy cleaning REFRIGERATION UNIT Electrical connection using Schuko plug 230V/1P/50Hz Monoblock ceiling system to enable use of the entire refrigerated volume Monoblock chiller unit removable from above for simple and easy servicing and replacement Refrigerant R134a for TN units and R404A for BT units Controlled forced-air cooling system to guarantee the maximum efficiency and uniformity throughout the cabinet Automatic defrost cycles for energy savings Defrost water evaporation system with superheated gas For appliances with remote cooling unit, defrost water evaporation by means of thermostatic resistor CONTROLS AND SAFETY DEVICES Control for adjusting the relative humidity inside the cabinet from a minimum to a maximum Control equipped with cabinet probe and evaporator probe Compressor protected by overheat cut-out with automatic reset Evaporator fan stops automatically when door is opened Door lock with key on request Alarm signalling: HACCP, AH/AL (high/low temperature), Door Open
